malariasimple is designed to resemble malariasimulation as closely as possible. However, there are certain scenarios (e.g. fast, low resolution runs; low population/transmission scenarios) where malariasimple may not provide a useful approximation. If in doubt, it is a good idea to check your malariasimple simulation against an equivalent malariasimulation run. In this vignette we will demonstrate some examples of comparing equivalent simulations of malariasimulation with both deterministic and stochastic runs of malariasimple.

Note: malariasimple is designed to be familiar to users of malariasimulation and hence many functions have the same name. Hence, when both libraries are loaded in an R session simultaneously, it becomes necessary to state which version of a function you are calling by using the :: operator.

library(malariasimple)
set.seed(101)

Example

Set up parameters

n_years <- 3
human_pop <- 5000
n_days <- n_years*365
init_EIR <- 50
num_sims <- 10 #Number of parallel stochastic simulations

##Seasonality parameters
g0 <- 0.28
g <- c(-0.3, -0.03, 0.17)
h <- c(-0.35, 0.32, -0.07)

##Define ITN parameters
itn_days <- c(100,365,500,800)
itn_cov <- c(0.1,0.4,0.5,0.1)
gamman <- 2.64*365
retention <- 5*365

##Define SMC parameters
smc_offsets <- c(-60, -30, 0, 30)
peak_cc <- get_peak_cc(g0, g, h)
smc_days <- rep(365 * seq(1, n_years - 1, by = 1), each = length(smc_offsets)) +
  peak_cc +
  rep(smc_offsets, 2)
smc_cov <- seq(0.3,0.6, length.out = length(smc_days))
smc_min_age <- 0.25*365
smc_max_age <- 5*365

malariasimulation

##Set up malariasimulation parameters
n_dist <- length(itn_days)
dn0 <- rep(0.41, n_dist)
rn <- rep(0.56, n_dist)
rnm <- rep(0.24, n_dist)
gamman_vec <- rep(gamman, n_dist)

malsim_params <- malariasimulation::get_parameters(
  overrides = list(
    model_seasonality = TRUE,
    g0 = g0,
    g = g,
    h = h,
    clinical_incidence_rendering_min_ages = 0,
    clinical_incidence_rendering_max_ages = 100 * 365,
    prevalence_rendering_min_ages = 2 * 365,
    prevalence_rendering_max_ages = 10 * 365,
    human_population = human_pop
  )
) |>
  malariasimulation::set_drugs(list(malariasimulation::SP_AQ_params)) |>
  malariasimulation::set_smc(
    drug = 1,
    timesteps = smc_days,
    coverages = smc_cov,
    min_ages = rep(smc_min_age, length(smc_days)),
    max_ages = rep(smc_max_age, length(smc_days))
  ) |>
  malariasimulation::set_bednets(
    timesteps = itn_days,
    coverages = itn_cov,
    retention = retention,
    dn0 = matrix(dn0, nrow = n_dist, ncol = 1),
    rn = matrix(rn, nrow = n_dist, ncol = 1),
    rnm = matrix(rnm, nrow = n_dist, ncol = 1),
    gamman = gamman_vec
  ) |>
  malariasimulation::set_equilibrium(init_EIR = init_EIR)

##Run malariasimulation
malsim <- malariasimulation::run_simulation_with_repetitions(
  timesteps = n_days,
  repetitions = num_sims,
  parameters = malsim_params
)

malariasimple - deterministic

##Set up deterministic malariasimple parameters
simple_det_params_1 <- malariasimple::get_parameters(
  n_days = n_days,
  prevalence_rendering_min_ages = 2 * 365,
  prevalence_rendering_max_ages = 10 * 365,
  human_pop = human_pop
) |>
  malariasimple::set_seasonality(
    g0 = g0,
    g = g,
    h = h
  ) |>
  malariasimple::set_bednets(
    days = itn_days,
    coverages = itn_cov,
    gamman = gamman,
    retention = retention
  ) |>
  malariasimple::set_smc(
    min_age = smc_min_age,
    max_age = smc_max_age,
    days = smc_days,
    coverages = smc_cov,
    distribution_type = "random"
  ) |>
  malariasimple::set_equilibrium(init_EIR = init_EIR)

##Run determistic malariasimple
simple_det_1 <- malariasimple::run_simulation(simple_det_params_1) |> as.data.frame()

malariasimple - stochastic

##Set up stochsatic malariasimple parameters
simple_stoch_params_1 <- malariasimple::get_parameters(
  n_days = n_days,
  prevalence_rendering_min_ages = 2 * 365,
  prevalence_rendering_max_ages = 10 * 365,
  stochastic = TRUE,
  human_pop = human_pop
) |>
  malariasimple::set_seasonality(
    g0 = g0,
    g = g,
    h = h
  ) |>
  malariasimple::set_bednets(
    days = itn_days,
    coverages = itn_cov,
    gamman = gamman,
    retention = retention
  ) |>
  malariasimple::set_smc(
    min_age = smc_min_age,
    max_age = smc_max_age,
    days = smc_days,
    coverages = smc_cov,
    distribution_type = "random"
  ) |>
  malariasimple::set_equilibrium(init_EIR = init_EIR)

##Run stochastic malariasimple
simple_stoch_1 <- malariasimple::run_simulation(simple_stoch_params_1, n_particles = num_sims) |>
  make_2d()

Plot

par(mar = c(4, 4, 2, 1), cex = 0.4)  # Minimal margins # Adjust margins (bottom, left, top, right)
plot(NULL, xlim = c(0, max(n_days)), ylim = c(0, max(malsim$n_detect_lm_730_3650 / malsim$n_age_730_3650,
                                                     simple_stoch_1$n_detect_730_3650 / simple_stoch_1$n_730_3650,
                                                     simple_det_1$n_detect_730_3650 / simple_det_1$n_730_3650)),
     xlab = "Time (Days)", ylab = expression(italic(Pf)~PR[2-10]))

abline(v = itn_days, col = "#619CFF", lty = 2, lwd = 0.7)
abline(v = smc_days, col = "#00BA38", lty = 2, lwd = 0.7)

for (i in unique(malsim$repetition)) {
  lines(malsim$timestep[malsim$repetition == i],
        malsim$n_detect_lm_730_3650[malsim$repetition == i] / malsim$n_age_730_3650[malsim$repetition == i],
        col = rgb(0, 0, 0, alpha = 0.4), lty = 1, lwd = 0.7)
}

for (i in unique(simple_stoch_1$particle)) {
  lines(simple_stoch_1$time[simple_stoch_1$particle == i],
        simple_stoch_1$n_detect_730_3650[simple_stoch_1$particle == i] / simple_stoch_1$n_730_3650[simple_stoch_1$particle == i],
        col = rgb(244/255, 165/255, 130/255, alpha = 0.6), lty = 1, lwd = 0.7)
}

lines(simple_det_1$time,
      simple_det_1$n_detect_730_3650 / simple_det_1$n_730_3650,
      col = "#CA0020", lwd = 1.5)

legend("topright", legend = c("malariasimple - deterministic", "malariasimple - stochastic", "malariasimulation", "ITN distribution", "SMC distribution"),
       col = c("#CA0020", "#F4A582", "black", "#619CFF", "#00BA38"),
       lty = c(1,1,1,2,2), lwd = c(1.5,0.7,0.7,0.7,0.7), bty = "o", cex = 0.8)
